PROGRAMATOR UNIVERSAL DE MEMORII XELTEK SUPERPRO 610P | 48 PINI | USA

Universal IC Chip Device Programmer

PRODUS IN USA

Full Device List

Highlights

• Universal 48-pin driver supports today's most complex devices
• Improved programming processor for high-speed programming
• Programs devices with Vcc as low as 1.2V

Expanded Features

• Universal 48-pin driver supports today's most complex devices
• Improved programming processor for high-speed programming
• Programs devices with Vcc as low as 1.2V
• In-system programming (ISP / ICP) capability
• Programming / testing features for TTL/CMOS logic ICs and memories
• Only IC manufacturer approved programming algorithms used for high reliability
• Over-current and over-voltage protection for safety of the chip and programmer hardware
• Compatible with Windows XP / Vista / 7 / 8 (32/64 bit)
• Vcc verification (at +5% ~ -5% and +10% ~ -10%) enhances programming reliability
• Advanced and powerful software functions:
• The Project function simplifies processes such as device selection, file loading, device configuration setting, program option, and batch file setting into one step.
• Password protection provides security for project files and production volume control.
• The Batch command combines device operations like program, verify, security into a single command at any sequence.
• Serial number generators are available as standard or customer-specific functions.
• A Log file provides quality tracking

Volume Production Solution (Clustering available)
The capability of operating multiple programmers simultaneously allow users to easily set up stand-alone programmers for high volume production environment.
Compact Flash (CF) card is necessary to store user data and device algorithm in stand-alone operation. 256 MB is recommended for most operations.

Click here for more information about Volume Production Solution

Hardware & electrical Specifications

• Devices Supported: EPROM, Paged EPROM, Parallel and Serial EEPROM, FPGA Configuration PROM, FLASH memory (NOR), BPROM, NVRAM, SPLD, CPLD, EPLD, Firmware HUB, Microcontroller, MCU
• Package: DIP, SDIP, PLCC, JLCC, SOIC, QFP, TQFP, PQFP, VQFP, TSOP, SOP, TSOPII, PSOP, TSSOP, SON, EBGA, FBGA, VFBGA, uBGA, CSP, SCSP,…
• PC interface: USB2.0 (High speed)
• Power supply: AC Adapter: Input AC 90V- 250V, 50/60Hz; DC Output: 12V/2A; power 15W
• Main unit: Dimensions 178mm (L) * 130mm (W) * 40mm (H) Weight 0.85 lbs (0.38Kg)
• Package: Dimensions 320mm (L) * 300mm (W) * 85mm (H) Weight 3 lbs (1.8Kg)

Items Included

• SuperPro 610P Programmer
• AC adapter
• Software CD
• USB Cable

Universal 48-pin driver supports today's most complex devices
Improved programming processor for high-speed programming
Programs devices with Vcc as low as 1.2V
